Product Description

Subaru Impreza 6 Speed Exedy Racing Hyper Twin Plate Clutch & Flywheel Kit

Subaru Impreza New Age WRX STI 6 speed 2.0 & 2.5 litre models or classic 5 to 6 speed gearbox conversions.

For high-powered applications, the EXEDY multi plate clutch is capable of handling a variety of fast road and motorsport applications.

CENTER PLATE SELF LEVELLING FUNCTION (PAT.)

The amount of centre plate travel during release is always maintained in a neutral position by the reaction force of the lifting plate attached to both sides of the centre plate.

PULL TYPE CLUTCH CUSHIONING FUNCTION (PAT.) (CLUTCH THRUST & FLYWHEEL SPIGOT BEARING NOT INCLUDED - PLEASE ENQUIRE)

The "CUSHION" function is an innovation unique to EXEDY. The half engaged "ZONE" is expanded as a result of a decrease in rigidity of the pivot ring. Ideal pedal effort is achieved as a result of a longer lever ratio of the diaphragm spring coupled with the cushion reaction force.

MAIN BENEFITS

  • Self-levelling intermediate plate design reduces gearbox rattle and increases the disengagement performance (PAT.).
  • Unique intermediate plate design increases heat resistance which improves clutch life.
  • 20 to 30% reduction in inertia vs OEM

SUITABLE FOR

Street Modified / Track day / Circuit Racing / Time Attack / Drift / Drag

All Hyper Series clutches come with a chromoly steel flywheel and forged aluminium clutch cover, which has no clamp load deflection as found in a pressed metal cover.

Clutch Type: Hyper Multi Twin
Friction Facing: Cerametallic
Disc Diameter (mm): 200
Sprung Centre:  Yes
Clamp Load (N): 9810
Torque at Flywheel: 600 lb-ft / 810 Nm
Torque at Wheels: 480 lb-ft / 650 Nm

Specifications

Brand
Exedy
Product Code
RCM1077
